TSV52 op-amp series: When power to performance matters
The TSV521, TSV522 and TSV524 are single, dual, and quad rail-to-rail input and output single-supply, micro power amplifiers operating from 2.7 to 5.5 V. They feature a very low supply current per amplifier of 45 µA while providing a 1.15 MHz bandwidth. These are thus high merit factor op amps.
In addition, the TSV52 series offers an input offset voltage down to 800 µV which is far better than its counterparts available on the market. The TSV52 series sets an industry-leading power-to-performance ratio for rail-to-rail amplifiers.
These unmatched performances housed in tiny packages makes the TSV52 series of op amps ideally suited for small-signal conditioning applications.
Features
- Enhanced merit factor: 1.15 MHz for 45 µA
- Lower offset VIO down to 800 µV
- Space saving DFN8 2 x 2 mm for dual op amps
- Low input bias current
- Rail-to-rail input and output
- Operating range: 2.7 to 5.5 V
- Higher ESD protection: 4 kV
- Automotive grade availability
Applications
- Battery-powered and portable devices
- Active filtering
- Sensor interfaces
- Photodiode amplifiers
- Piezoelectric transducer amplifiers
- Medical instrumentation
Ordering
Order code | Input offset voltage VIO max (mV) | Automotive grade | Package |
TSV521ICT |
| - | SC70-5 |
TSV522IQ2T |
| - | DFN8 2x2 |
TSV522IST |
| - | MiniSO8 |
TSV524IQ4T |
| - | QFN16 3x3 |
TSV524IPT |
| - | TSSOP14 |
TSV522IYST |
| yes | MiniSO8 |
TSV524IYPT |
| yes | TSSOP14 |
TSV521AICT |
| - | SC70-5 |
TSV522AIQ2T |
| - | DFN8 2x2 |
TSV522AIST |
| - | MiniSO8 |
TSV524AIQ4T |
| - | QFN16 3x3 |
TSV524AIPT |
| - | TSSOP14 |
TSV522AIYST |
| yes | MiniSO8 |
TSV524AIYPT |
| yes | TSSOP14 |
