LSM303D is a system in package featuring a 3D magnetometer and a 3D high resolution accelerometer.
It is the latest generation of E-compass from STMicroelectronics with high flexibility, high stability over temperature for a consumption of only 300 uA in normal mode and 1 uA in power-down mode (Accelerometer and Magnetometer).
Interrupt generators can be configured by the user for free-fall, motion detection and magnetic field detection.
It is available in a LGA-16 package 3 x 3 x 1 mm³.
LSM303D has the same footprint as the 3x3 accelerometer standalone (LIS3DH and LIS3DSH).
STEVAL-MKI109V2
STM32-based MEMS motherboard compatible with ST MEMS adapters
Daughter board available:
LSM303D
STEVAL-MKI133V1
Features
■ 3-axis magnetic sensor: from 2 to 12 gauss full-scale
■ 3-axis accelerometer: from 2 to 16g full-scale
■ 16-bit data output
■ SPI / I²C serial interfaces
■ Current consumption: 300uA (A and M)
■ Programmable interrupt generators for free-fall, motion detection and magnetic field detection
■ Power-down mode / low-power mode
■ Embedded temperature sensor & FIFO for accelerometer
Applications
■ Compensated Compass
■ Location based services
■ Map rotation
■ Personal navigation
■ Enhanced position detection
■ Free-fall detection
