element14 DIY Drawdio Kit - Maker Faire Giveaway

http://www.element14.comimage


Background:


Jay Silver of MIT Media Lab created the clever & fun Drawdio:


http://www.drawdio.com/


The Drawdio is a pencil that lets you draw music or, in more general sense, turn almost anything into a "theremin"!


Thanks to the power of Open Source Hardware, Limor Fried of Adafruit Industrires was able to design a fantastic DIY electronics kit based on Jay's Drawdio design:


http://www.ladyada.net/make/drawdio/index.html


The circuit board, or PCB, was designed with CadSoft EAGLE as are all of Adafruit's kits.  They also release full design files and source code (when software is used) for all their project & kits.



Instructions:


At Maker Faire NYC, the element14 booth will be giving away Drawdio kits containing the PCB from Adafruit and electronics components sourced from the element14 Store.  If you received such a kit, then please use the Adafruit Drawdio v1.1 instructions to build your kit:



SOLDER IT! @  http://www.ladyada.net/make/drawdio/solder.html


NOTE: The ceramic capacitors included in the element14 kit differ slightly from the illustrations in adafruit's instructions:


  • Both ceramic capacitors in the element14 kit are yellow.  The smaller one, marked '681' and packaged on cardboard, is C1 (680pF).
  • The larger yellow capacitor is C3 (0.1 uF).
  • Also, the 300K resistor RB included with the kit is dark brown, but of course has the same colour code (Orange Black Yellow Gold) indicated in the instructions.


Please also note that Adafruit can not provide support for these element14 Drawdio kits.  Please post any questions or concerns in the element14 Drawdio kit discussion thread in this Open Source Hardware Group.



Bill of Materials:


Adafruit Industries:

    • Drawdio v1.1 PCB (Printed Circuit Board)


element14 electronic components:


SKU               Qty     Desc

08F9140           1    TEXS INSTRUMENTS TL551CPTEXS INSTRUMENTS TL551CP

83C0266           1     BIPOLAR TRANSISTOR, PNP, -60VBIPOLAR TRANSISTOR, PNP, -60V

46P6336           1     CAPACITOR CERAMIC 680PF, 100V, X7R, RADIALCAPACITOR CERAMIC 680PF, 100V, X7R, RADIAL

56K3637           1     CAPACITOR CERAMIC 0.1UF, 100V, X7R, 10%, RAD CAPACITOR CERAMIC 0.1UF, 100V, X7R, 10%, RAD

23K3685           1     CAPACITOR ALUM ELEC 100UF, 6.3V, 20%, RADIAL CAPACITOR ALUM ELEC 100UF, 6.3V, 20%, RADIAL

58K4999           1     RESISTOR, CARBON FILM, 10 OHM, 250mW, 5%RESISTOR, CARBON FILM, 10 OHM, 250mW, 5%

58K5002           1     RESISTOR, CARBON FILM, 10KOHM, 250mW, 5% RESISTOR, CARBON FILM, 10KOHM, 250mW, 5%

73K0308           1     RESISTOR CARBON, 300KOHM, 250mW, 5%RESISTOR CARBON, 300KOHM, 250mW, 5%

58K5005           1     RESISTOR, CARBON FILM, 10MOHM, 250mW, 5%RESISTOR, CARBON FILM, 10MOHM, 250mW, 5%

96K2702           1     Speaker
16F1095           1     BATTERY HOLDER, AAA, THDBATTERY HOLDER, AAA, THD

33C7229           1     HOOK_UP WIRE 25FT BLACKHOOK_UP WIRE 25FT BLACK                                             *Each kit only needs 3"
33C7233          1     HOOK-UP WIRE, 25FT, 22AWG, CU, REDHOOK-UP WIRE, 25FT, 22AWG, CU, RED                                             *Each kit only needs 3"


Newark Electronics:

96F9287    Qty 1     TAPE, FOIL SHIELD, COPPER, 0.25INX18YD TAPE, FOIL SHIELD, COPPER, 0.25INX18YD *Each kit only needs 6" of foil tape


Misc Parts:
  • 2B Graphite Pencil with no eraser, open top (Blick or any art supply store)
  • Thumbtack
  • Small Zip Tie / Cable Tie
  • maker
  • openhardware
  • nyc
  • faire
  • newyork
  • theremin
  • makerfaire
  • mit
  • ohs
  • hardware
  • oshw
  • ladyada
  • make
  • diy
  • hobbyist
  • drawdio
  • adafruit
  • Share
  • History
  • More
  • Cancel
  • Sign in to reply
  • fustini
    fustini over 14 years ago

    Hope everyone is enjoying their element14 Drawdios!



    I was thrilled we were able to giveaway this terrific kit created by Adafruit & Jay Silver.  I'd love to hear about the experience of building the kit that everyone had - and any creative modification you might have made!



    Cheers,

    Drew

    http://us.element14.com/pdp7

    • Cancel
    • Vote Up 0 Vote Down
    • Sign in to reply
    • More
    • Cancel
  • Former Member
    Former Member over 14 years ago
    Wow this is really cool
